Hikvision ColorVu 3.0 Hybrid offers the freedom to choose or combine: 3 functions in 1 camera. This camera series is suitable both as a day/night camera and for 24/7 colour imaging. The combination of ColorVu technology with IR functionality makes the camera versatile. Thanks to its super aperture and highly light-sensitive sensor, this camera delivers unrivalled image quality, even in low light. Advanced noise reduction and an innovative light compensation function (Auto WDR) ensure a clear and balanced image under all conditions.
With Smart Hybrid Light, the camera automatically switches between lighting modes. In low-light situations, night mode with IR illumination is activated. Upon detection of a person or vehicle, the camera immediately switches to colour mode with white LED backlighting. This optimally highlights the scene, displays objects in colour and creates a deterrent effect for unwanted visitors.
- High-resolution 8MP camera with 25fps
- ColorVU 3.0 technology for 24/7 colour image, black and white or VCA triggered colour image
- 24/7 colour image by backlighting with white LED up to 60 metres
- AcuSense technology for intellegent detection with object classification
- Active warning by audio and/or light signal
- Built-in microphone and speaker for 2-way audio
- NEMA4X Anti corrosion coating
- Efficient H.265+ compression technology
Specificaties:
-
Camera
- Number of image sensors: 1
- Optical/Thermal: Optical
- Beeldsensor: 1/1.8
- Resolution: 3840 x 2160
- Pixel count: 8MP
- Minimum illumination strength (in colour): 0.001 Lux
- Minimum illumination strength (LED on (black/white)): 0 Lux
- Lighting: IR, Strobe Lighting, White LED
- LED distance: up to 60m
- LED On/Off (Day/Night): Auto/Manual
- Shutter speed: 1/3s ~ 1/100,000s
- Noise reduction: 3DNR
-
Lens
- Lens type: Motor zoom lens
- Iris: Fixed Iris
- Focal distance: 2.8mm ~ 12mm
- Maximum aperture: F1.2
- Horizontal aperture angle: 112.3° ~ 41.2°
- Vertical aperture angle: 58.1° ~ 23.1°
- Focus control: Auto/Manual
-
Video
- Stream capability: 3 streams
- Video compression: H.264, H.264 +, H.265, H.265 +, MJPEG
- Frames per second (Main stream): 25 fps @3840 × 2160
- 2nd stream: 25 fps @1280 × 720
- 3rd stream: 10 fps @1920 × 1080
- Bitrate: 32 Kbps ~ 16 Mbps
- Day/Night: Auto (filter), Colour, Black/White
- Light compensation: BLC, HLC, WDR (130dB)
- Motion detection: On/Off
- Smart Functions:
- AI Face Capture/Attributes
- AI Perimeter Protection
- Object Classification
- Intrusion Detection
- Line Crossing
- Region Entrance Detection
- Region Exiting Detection
- Scene Change Detection
- Smart IR: Yes
- Smart LED: Auto/Manual
- Electronic Image Stabilisation (EIS): Yes
- Defog: No
- Privacy masking: Yes
-
Audio
- Built-in microphone: yes
- Audio input: Yes
- Audio Output: Yes
- Audio Compression: AAC, G.711, G.722.1, G.726, MP2L2
- Speaker: Yes
-
Netwerk
- Ethernet: 1 RJ45 10M/100M self-adaptive Ethernet port
- Storage option SD card: yes
- Maximum Storage Capacity SD card: 512GB
-
Interface
- RS-485: No
- Alarm: Yes
- Number of channels in: 1 input max 24 VDC/24 VAC, 1 A
- Number of channels out: 1 output max 24 VDC/24 VAC, 1 A
-
Elektrisch
- Power supply included: no
- Power supply: 12V DC, PoE +(Type IEEE 802.3at)
- Max Consumption: 12V max 14.5 W
- PoE max. 18W
-
Omgeving
- Operating temperature: -30°C ~ +60°C
- Waterdichtheid: IP67
- Vandal resistant: IK10
-
Constructie
- Material: Metal
- Diameter: Ø150.1mm
- Height: 95.7mm
- Width: 97.9mm
- Depth: 297.9mm
- Weight: 1.6 Kg
