Stay connected, secure and powered with the Reolink D340B paired with the Home Hub1, a wireless battery-powered doorbell camera system for your front door. With a 1:1 aspect ratio, the doorbell provides a head-to-toe view for wider coverage and unmatched visibility. Supporting up to 8 Reolink cameras, the hub is ideal as a storage, alarm and management center for your DIY camera system. What's more, by adopting an advanced technology (Sub-1G) that reduces power consumption, the doorbell battery life is extended from max 5 to max 6 months. So you can enjoy more time between charges!
- 2K/4MP (2048x2048) resolution, with a unique 1:1 aspect ratio and a viewing width of 150x150x180 degrees, you have an excellent view of your front door from head to toe.
- 5/2.4 GHz Dual-Band WiFi connection.
- Visitor notification. Receive an immediate push notification when a visitor rings the bell. You can see the visitor without opening the door.
- Smart detection and real-time alerts. When detecting people, vehicles or packages, you will receive an immediate notification.
- HDR technology. This technology dynamically adjusts exposure to improve image quality. You are assured of clear and detailed images, even in difficult lighting conditions.
- Live streaming up to 16MP. Connect multiple cameras (up to 8) to the Hub for easy access to live feeds and recordings up to 16MP, all through an easy-to-use interface.
- Enjoy encrypted local storage at no extra cost. Start with an included 128GB micro SD card and expand up to 2×512GB (there are two card slots) for all your needs.
Specifications:
- Model: Reolink D340B
- Video & Audio
- Sensor: 1/3.11" CMOS Sensor
- Resolution: 2048x2048 (4 Megapixels) @15 frames/sec
- Lens: f=1.2mm; F=1.8, fixed
- Viewing angle: Horizontal: 150°, Vertical: 150°, Diagonal: 180°
- Audio: Two-way audio, noise reduction, echo cancellation
- Video compression: H.264/H.265
- Current
- Battery: 7000mAh rechargeable battery (life varies with settings, usage and temperature)
- Wired: 8-24V AC, 24V DC
- Interface
- Power port: USB-C port
- SD card slot: Supports max 256GB micro SD card
- Reset, On/Off button: Yes
- Audio in/out: Built-in microphones (2) and speaker
- WiFi
- Wireless standard: IEEE 802.11 a/b/g/n
- Frequency: 2.4GHz/5GHz
- Wireless security: WPA/WPA2
- Software
- Network protocol: SSL, TCP/IP, UDP, UPNP, STMP, NTP, P2P
- OS support: PC: Windows, Mac OS; Smart Phone: iOS, Android
- Other features
- Smart Alarm: Motion/person/vehicle/package detection, visitor notification
- Smarthome compatibility: Google Assistant, Alexa
- Recording mode: Motion activated recording
- Cloud storage: Supports Reolink Cloud
- Rich notifications: Yes (Reolink Cloud subscription required)
- Quick response/answers: Yes
- Working environment
- Operating temperature: -10° ~ 55° C
- Operating humidity: 10%~90%
- Weatherproof: IP65 certified
- Mechanical
- Size: 160 x 48 x 29.5 mm
- Weight: 231gr
- Model: Reolink Home Hub1
- Device Management
- Camera: Up to 8 cameras
- Device Compatibility: All Reolink WiFi/PoE cameras (Battery cameras need firmware upgrade)
- Safety protection: Account access and sharing options for individual devices are only available through the Home Hub
- Input/Output
- HDMI: No
- USB: No
- Reset button: Yes
- Current: DC 12V/1A
- Speaker: Yes (max 115 dB)
- Ethernet: 1x 10M/100Mbit RJ45 port for WAN
- Storage
- SATA: No
- Micro SD card slot: Up to 512GB x2
- Backup media: No
- Storage Encoding: Protects privacy and prevents theft with AES-128 encryption algorithm
- Preview & Playback
- Live View: App, PC Client
- Playback: Smart Playback / Event History
- WiFi
- Wireless standard: IEEE 802.11 a/b/g/n/ac/ax (WiFi 6)
- Frequency: 2.4/5 GHz
- Wireless security: WPA/WPA2/WPA3
- Sub-1 GHz
- System
- Network protocol: TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, RTMP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
- OS: PC: Windows, MacOS; Smartphone: iOS, Android
- Max user access: 11 users (1 admin account & 10 shared accounts)
- Smart Home: Google Assistant
- Environment
- Operating temperature: -10°C ~ +45°C
- Operating humidity: 10% ~ 90%
- Mechanical
- Size: 95x95x161.8mm
- Weight: 441gr
